181
Installation and Maintenance
Service Manual
Above data is subject to change without notice.
NO.
Description
Part Code
Qty
GWH18YD-K6DNA1A/O GWH24YE-K6DNA1A/O
Product Code CB437W01300 CB437W01400
1 Front Grill 22413045 22415010 1
2 Front Panel 01535013 01535013P 1
3 Drainage Connecter 06123401 06123401 1
4 Chassis Sub-assy 02803231P 01205816P 1
5 Drainage hole Cap 06813401 06813401 3
6 Compressor and ttings 00103919G 00103920 1
7 Magnet Coil 4300040045 4300040087 1
8 4-Way Valve Assy 03015200069 03073274 1
9 Cut off Valve Assy 07133774 07133844 1
10 Cut off Valve Sub-Assy 07133204 07133843 1
11 Valve support assy 01715010P 01705046P 1
12 Right Side Plate 0130509402P 0130509001P 1
13 Valve cover 2623525404 22245002 1
14 Handle 26233053 26233053 1
15 Wiring Clamp 26115004 26115005 1
16 Rear Grill 01473043 01475020 1
17 Condenser Assy 011002000308 011002000244 1
18 Reactor / / /
19 Clapboard Assy 01233153 01235081 1
20 Coping 01255005P 012049000007P 1
21 Supporting Board(Condenser) 01795010 01795031 1
22 Motor Support Sub-Assy 01705036 01705067 1
23 Fan Motor 1501506402 1501506402 1
24 Axial Flow Fan 10335008 10335008 1
25 Left Side Plate 01305093P 01305093P 1
26 left handle 22245002 2623525404 1
27 Electric Box Assy 100002000414 100002000470 1
28 Wire Clamp 71010003 71010102 1
29 Terminal Board 420101943 422000060009 1
30 Electric Box 20113027 20115003 1
31 Radiator 49013060 4901521502 1
32 Main Board 300027000083 300027000081 1
33 Insulated Board (Cover of Electric Box) 20113003 / 1
34 Temperature Sensor 3900030901 3900030902 1
35 Electric Expansion Valve Sub-Assy 030174000058 030174000049 1
