Installation and Maintenance
Service Manual
Above data is subject to change without notice.
No.
Description
Part Code
Qty
GWH09AGA-K6DNA1A/O GWH12AGB-K6DNA1A/O
Product Code CB385W01000 CB385W01700
1 Coping 01204906008701P 01204906008701P 1
2 Supporting Board(Condenser) 012072061032 012072061032 1
3 4-Way Valve 430004022 430004022 1
4 Sponge(Condenser) 1212309101 1212309101 1
5 Temperature Sensor Support 24213042 24213042 1
6 Condenser Assy 011002061289 011002061317 1
7 Capillary Sub-assy 030006060901 030006060915 1
8 Sensor Insert 42020063 42020063 1
9 Right Side Plate 01205606031101P 01205606031101P 1
10 Earthing Plate Sub-assy 012002060009 012002060009 1
11 Wire Clamp 71010103 71010103 1
12 Handle Assy 000223000006 000223000006 1
13 Silencer 07243067 07243067 1
14 Cut-off valve 1/4(N) 07000106001501 07000106001501 1
15 Cut-off valve 3/8(N) 07000106001401 07000106001401 1
16 Valve Support 012044060018P 012044060018P 1
17 4-Way Valve Assy 030152060486 030152060486 1
18 Compressor and Fittings 009001060484 009001060497 1
19 Chassis Sub-assy 017000060511P 017000060511P 1
20 Motor Support 01204806011103 01204806011103 1
21 Brushless DC Motor 1501308517 1501308517 1
22 Axial Flow Fan 10333428 10333428 1
23 Cabinet 012022060007P 012022060007P 1
24 Front Grill 200057060007 200057060007 1
25 Drainage Joint(ODU) 26113009 26113009 1
26 Left Side Plate 012055060256P 012055060256P 1
27 Clapboard 017021060544 017021060544 1
28 Electric Box Assy 100002069939 100002070042 1
29 Electric Box 200013060073 200013060073 1
30 Main Board 300027061312 300027061355 1
31 Electric Box Cover 200082060058 200082060058 1
32 Terminal Board 422000060016 422000060016 1
33 Temperature Sensor 3900030907 3900030907 1
34 Radiator 430034060108 430034060108 1
To Next Page
