Gree GWH12AGB-K6DNA1A/O

32
Technical Information
Service Manual
Model GWH09QA-K6DNB2A GWH12QB-K6DNB2A
Product Code CB432025400 CB432025500
Power
Supply
Rated Voltage V~ 220-240 220-240
Rated Frequency Hz 50 50
Phases 1 1
Power Supply Mode Outdoor Outdoor
Cooling Capacity W 2500 3200
Heating Capacity W 2800 3400
Cooling Power Input W 720 991
Heating Power Input W 750 916
Cooling Power Current A 3.2 4.4
Heating Power Current A 3.2 4
Rated Input W 1500 1500
Rated Current A 6 6
Rated Heating Current A 7.5 7.5
Air Flow Volume(SS/H/MH/M/ML/L/SL) m
3
/h 500/420/390/300 590/480/410/280
Dehumidifying Volume L/h 0.80 1.4
EER W/W 3.47 3.23
COP W/W 3.73 3.71
SEER W/W 6.5 6.1
HSPF W/W / /
Application Area m
2
12-18 15-22
Indoor Unit
Indoor Unit Model GWH09QA-K6DNB2A/I GWH12QB-K6DNB2A/I
Indoor Unit Product Code CB432N25400 CB432N25500
Fan Type Cross-ow Cross-ow
Diameter Length(DXL) mm Ф98X507 Ф98X580
Fan Motor Cooling Speed(SS/H/MH/M/ML/L/SL) r/min 1300/1200/1000/800 1350/1200/1050/750
Fan Motor Heating Speed(SS/H/MH/M/ML/L/SL) r/min 1300/1200/1000/800 1350/1200/1050/850
Output of Fan Motor W 10 20
Fan Motor RLA A 0.2 0.22
Fan Motor Capacitor μF 1 1
Input of Heater W / /
Evaporator Form Aluminum Fin-copper Tube Aluminum Fin-copper Tube
Pipe Diameter mm Φ5 Φ5
Row-n Gap mm 2-1.5 2-1.4
Coil Length (LXDXW) mm 510X22.8X266.7 584X22.8X266.7
Swing Motor Model MP24AA MP24AA
Output of Swing Motor W 1.5 MP24AA
Fuse A 3.15 3.15
Sound Pressure Level(SS/H/MH/M/ML/L/SL) dB (A)
Cooling:39/36/32/25
Heating:39/36/33/26
Cooling:41/37/33/24
Heating:42/38/33/27
Sound Power Level(SS/H/MH/M/ML/L/SL) dB (A)
Cooling:55/48/44/37
Heating:49/48/45/38
Cooling:57/50/45/34
Heating:53/51/46/39
Dimension (WXHXD) mm 714X270X195 790×275×200
Dimension of Carton Box (LXWXH) mm 760X334X259 850×339×262
Dimension of Package (LXWXH) mm 763X350X270 852×355×273
Net Weight kg 8 9
Gross Weight kg 9.5 11
