Service Manual
3. Outline Dimension Diagram
3.1 Indoor Unit
Model W H D
09K 790 275 200
12K 845 289 209
18K 970 300 224
Unit:mm
W
D
H
90
150
54
168.5 462 159.5
Φ55
Φ55
54
123.5 541.6 179.9
83.2
124.7
35
Φ55
Φ55
35
09K Unit:
12K Unit:
104 685 181
140
190
38
Φ55
Φ55
38
18K Unit:
