Gree GWH12QC-K3DNA1B

83
Installation and Maintenance
Service Manual
No.
Description
Part Code
Qty
GWH18QD-K3DNA1B/O
3URGXFW&RGH CB419W02100
1 )URQW*ULOO 22413015 1
2 Cabinet 01433034P 1
3 $[LDO)ORZ)DQ 10333016 1
4 &KDVVLV6XEDVV\ 01205176P 1
5 Drainage Joint 26113009 1
6 &RPSUHVVRUDQG)LWWLQJV 00105249G 1
7 :D\9DOYH$VV\ 03025478 1
8 9DOYH6XSSRUW6XE$VV\ 01713115P 1
9 &XWRII9DOYH6XE$VV\ 07335707 1
10 &XWRII9DOYH6XE$VV\ 07335708 1
11 9DOYH&RYHU 22243005 1
12 Big Handle 26233431 1
13 5LJKW6LGH3ODWH 0130324403P 1
14 Magnet Coil 4300040045 1
15 Wire Clamp 71010003 1
16 7HPSHUDWXUH6HQVRU 3900030901 1
17 Rear Grill 01475019 1
18 Condenser Assy 01103000182 1
19 &ODSERDUG6XE$VV\ 01233168 1
20 Coping 01253034P 1
21 Reactor 43130186 1
22 0RWRU6XSSRUW6XE$VV\ 0170339802 1
23 )DQ0RWRU 1501307502 1
24 &RQGHQVHU6XSSRUW3ODWH 01173165 1
25 Left Side Plate 01303169P 1
26 Electric Box Assy 20102000309 1
27 Capacitor CBB61 33010010 1
28 Electric Box 20113027 1
29 Terminal Board 420111041 1
30 Radiator 4901302801 1
31 Main Board 30138000168 1
$ERYHGDWDLVVXEMHFWWRFKDQJHZLWKRXWQRWLFH
