Technical Information
Service Manual
Model GWH12AGC-K3NNA1B GWH18AGC-K3NNA1A
Product Code CA385000400
CA385000800
CA385000801
Power
Supply
Rated Voltage V~ 220-240 220-240
Rated Frequency Hz 50 50
Phases 1 1
Power Supply Mode Indoor Indoor
Cooling Capacity W 3550 4800
Heating Capacity W 3700 5300
Cooling Power Input W 1076 1476
Heating Power Input W 1025 1468
Cooling Current Input A 5.04 6.42
Heating Current Input A 4.8 6.38
Rated Input W 1300 2150
Rated Cooling Current A 7.42 11.62
Rated Heating Current A 6.82 11.35
Air Flow Volume(SS/H/MH/M/ML/L/SL) m
3
/h 680/620/560/490/450/420/390 650/590/530/480/410/370/340
Dehumidifying Volume L/h 1.4 1.8
EER W/W 3.30 3.25
COP W/W 3.61 3.61
SEER W/W / /
HSPF W/W / /
Application Area m
2
16-24 21-31
Indoor Unit
Model GWH12AGC-K3NNA1B/I GWH18AGC-K3NNA1A/I
Product Code CA385N00400
CA385N00800
CA385N00801
Fan Type Cross-ow Cross-ow
Fan Diameter Length(DXL) mm Φ98×630 Φ98×630
Cooling Speed r/min
1300/1150/1100/1000
/950/850/800
1300/1250/1200/1150
/1100/1050/1000
Heating Speed r/min
1250/1100/1050/1000
/950/850/800
1300/1250/1200/1150
/1100/1050/900
Fan Motor Power Output W 25 20
Fan Motor RLA A 0.3 0.3
Fan Motor Capacitor μF 1.5 1.5
Evaporator Form Aluminum Fin-copper Tube Aluminum Fin-copper Tube
Evaporator Pipe Diameter mm Φ5 Φ7
Evaporator Row-n Gap mm 2-1.4 2-1.4
Evaporator Coil Length (LXDXW) mm 634×22.8×304.8 634×25.4×304.8
Swing Motor Model MP24BA/MP24AK MP24BA/MP24AK
Swing Motor Power Output W 1.5/1.5 1.5/1.5
Fuse Current A 3.15 3.15
Sound Pressure Level dB (A)
Cooling:42/38/37/34/33/30/28
Heating:41/37/36/34/32/28/27
Cooling:40/39/38/36/35/34/32
Heating:40/39/38/37/36/35/30
Sound Power Level dB (A)
Cooling:52/48/47/44/43/40/38
Heating:51/47/46/44/42/38/37
Cooling:50/49/48/46/45/44/42
Heating:50/49/48/47/46/45/40
Dimension (WXHXD) mm 825X293X196 825X293X196
Dimension of Carton Box (LXWXH) mm 870X349X257 870X349X257
Dimension of Package (LXWXH) mm 875X365X268 875X365X268
Net Weight kg 10 10.3
Gross Weight kg 12 11.9
