9
Technical Information
Service Manual
Model GWH18AGD-K3NNA1B GWH24AGD-K3NNA1A
Product Code CA385000100 CA385000900 CA385000901
Power
Supply
Rated Voltage V~ 220-240 220-240
Rated Frequency Hz 50 50
Phases 1 1
Power Supply Mode Indoor Indoor
Cooling Capacity W 5275 6200
Heating Capacity W 5860 6700
Cooling Power Input W 1575 1907
Heating Power Input W 1583 1856
Cooling Current Input A 7.6 8.29
Heating Current Input A 7.6 8.07
Rated Input W 2100 2400
Rated Cooling Current A 12 13
Rated Heating Current A 12.5 12
Air Flow Volume(SS/H/MH/M/ML/L/SL) m
3
/h 940/840/740/690/640/590/540 950/840/740/690/640/590/540
Dehumidifying Volume L/h 1.8 1.8
EER W/W 3.35 3.25
COP W/W 3.70 3.61
SEER W/W / /
HSPF W/W / /
Application Area m
2
23-34 23-34
Indoor Unit
Model GWH18AGD-K3NNA1B/I GWH24AGD-K3NNA1A/I
Product Code CA385N00100 CA385N00900 CA385N00901
Fan Type Cross-ow Cross-ow
Fan Diameter Length(DXL) mm Φ106×739 Φ106×739
Cooling Speed r/min
1200/1100/1000/950
/900/850/800
1300/1200/1100/1000
/950/850/800
Heating Speed r/min
1150/1000/950/900
/850/800/750
1250/1150/1100/1050
/950/850/800
Fan Motor Power Output W 35 35
Fan Motor RLA A 0.45 0.35
Fan Motor Capacitor μF 3 3
Evaporator Form Aluminum Fin-copper Tube Aluminum Fin-copper Tube
Evaporator Pipe Diameter mm Φ5 Φ5
Evaporator Row-n Gap mm 2-1.4 2-1.3
Evaporator Coil Length (LXDXW) mm 745×22.8×342.9 745×22.8×304.8
Swing Motor Model MP24BA/MP24AK MP24AK/MP24BA
Swing Motor Power Output W 1.5/1.5 1.5/1.5
Fuse Current A 3.15 3.15
Sound Pressure Level dB (A)
Cooling:43/41/39/36/35/33/32
Heating:43/38/37/35/33/31/30
Cooling:45/42/40/37/35/33/32
Heating:47/44/42/40/38/33/32
Sound Power Level dB (A)
Cooling:53/51/49/46/45/43/42
Heating:53/48/47/45/43/41/40
Cooling:55/52/50/47/45/43/42
Heating:57/54/52/50/48/43/42
Dimension (WXHXD) mm 982X311X221 982X311X221
Dimension of Carton Box (LXWXH) mm 1039X377X287 1039X377X287
Dimension of Package (LXWXH) mm 1044x385X297 1044X385X297
Net Weight kg 13.7 13.7
Gross Weight kg 16 16
