Procedure
Step
Nut
Remove the nut xing axial ow blade and
then remove the axial ow blade.
7. Remove axial ow blade
Axial ow
blade
Remove the screws fixing motor and then
remove the motor.
Motor
8. Remove motor
Screws
Remove the screws xing motor support
and then remove the motor support.
Motor support
9. Remove motor support
Screws
Compressor
capacitor
To Next Page
