Gree MULTI24HP230V1CO - Page 41

39
Installation and Maintenance
Service Manual
Above data is subject to change without notice.
NO.
Description
Part Code
Qty
MULTI18HP230V1CO
Product Code CB228W04100
1 Front Grill 01473050 1
2 Front Panel Assy 01433069 1
3 Chassis Sub-assy 02803280P 1
4 Drainage Connecter / /
5 Drainage hole Cap / /
6 Gas-liquid Separator Assy 07223048 1
7 Compressor and Fittings 0010524501G 1
8 Electric Heater(Compressor) 7651873215 1
9 Tube Connector Sub-assy 06643008 1
10 Magnet Coil 4300040045 1
11 4-Way Valve Assy 03015200001 1
12 Right Side Plate 0131410000901P 1
13 Valve Support Assy 0713395401 1
14 Electronic Expansion Valve assy 0713395301 1
15 Valve Support Sub-Assy 07133845 1
16 Cut off Valve 071302391 1
17 Cut off Valve 07130239 1
18 Valve Cover / 1
19 Electric Expand Valve Fitting 43000084 1
20 Electric Expand Valve Fitting 4300008401 1
21 Temperature Sensor 39000073 1
22 Temperature Sensor 39000073 1
23 Wiring Clamp 26115004 1
24 Temperature Sensor 39000073 1
25 Rear Grill 01574100003 1
26 Condenser Assy 0116398001 1
27 Clapboard Assy 0123315301 1
28 Coping 01255006P 1
29 Supporting Board(Condenser) 01795010 1
30 Motor Support Sub-Assy 01705025 1
31 Fan Motor 1501403402 1
32 Left Side Plate 01305043P 1
33 Axial Flow Fan 10335014 1
34 Left Handle 26235401 1
35 Connecting Cable / /
36 Electric Box Assy 10000100020 1
37 Electric Box 20113015 1
38 Radiator / /
39 Main Board 30138000311 1
