GMV5 HR HEAT RECOVERY VRF Units Technical Sales Guide
GMV- Q120WM/B-F(U)
TC—Total capacity of outdoor unit; PI—Power input of outdoor unit
Combination
Outdoor
air temp
（℉
DB
）
Indoor air temp
57.2
℉
WB 60.8
℉
WB 64.4
℉
WB 66.2
℉
WB 68
℉
WB 71.6
℉
WB 75.2
℉
WB
68
℉
DB 73.4
℉
DB 78.8
℉
DB 80.6
℉
DB 82.4
℉
DB 86
℉
DB 89.6
℉
DB
TC PI TC PI TC PI TC PI TC PI TC PI TC PI
kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW
130%
50 105.4 4.42 125.6 5.40 145.7 6.42 151.3 6.56 153.0 6.43 156.9 6.16 160.7 5.87
53.6 105.4 4.49 125.6 5.50 145.7 6.55 149.1 6.52 151.3 6.39 154.7 6.11 158.6 6.02
57.2 105.4 4.58 125.6 5.60 145.3 6.62 147.4 6.49 149.1 6.35 153.0 6.30 156.9 6.37
60.8 105.4 4.66 125.6 5.72 143.6 6.60 145.3 6.55 147.0 6.57 150.9 6.64 154.7 6.70
64.4 105.4 4.75 125.6 5.84 141.4 6.84 143.1 6.88 145.3 6.92 149.1 6.98 153.0 7.05
68 105.4 4.85 125.6 6.21 139.3 7.18 141.4 7.22 143.1 7.26 147.0 7.32 150.9 7.40
69.8 105.4 4.98 125.6 6.43 138.4 7.35 140.6 7.39 142.3 7.42 146.1 7.50 150.0 7.57
73.4 105.4 5.35 125.6 6.89 136.7 7.68 138.4 7.72 140.1 7.76 144.0 7.84 147.9 7.91
77 105.4 5.71 125.6 7.39 134.6 8.02 136.7 8.06 138.4 8.11 142.3 8.19 146.1 8.26
80.6 105.4 6.09 125.6 7.90 132.9 7.06 134.6 8.41 136.3 8.44 140.1 8.53 144.0 8.62
84.2 105.4 6.51 125.6 8.44 130.7 8.69 132.4 8.74 134.6 8.79 138.4 8.88 142.3 8.97
87.8 105.4 6.95 125.1 8.93 128.6 9.04 130.7 1.34 132.4 9.13 136.3 9.23 140.1 9.33
91.4 105.4 7.40 123.0 9.27 126.9 9.36 128.6 9.43 130.7 9.48 134.6 9.58 138.0 9.70
95 105.4 7.89 120.9 9.61 124.7 9.72 126.9 9.77 128.6 9.83 132.4 9.94 136.3 10.04
98.6 105.4 8.39 119.1 9.95 123.0 10.07 124.7 10.12 126.9 10.19 130.3 10.30 134.1 10.42
102.2 105.4 8.93 117.0 10.29 120.9 10.41 123.0 10.47 124.7 10.54 128.6 10.65 132.4 10.78
Combination
Outdoor
air temp
（℉
DB
）
Indoor air temp
57.2
℉
WB 60.8
℉
WB 64.4
℉
WB 66.2
℉
WB 68
℉
WB 71.6
℉
WB 75.2
℉
WB
68
℉
DB 73.4
℉
DB 78.8
℉
DB 80.6
℉
DB 82.4
℉
DB 86
℉
DB 89.6
℉
DB
TC PI TC PI TC PI TC PI TC PI TC PI TC PI
kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW
120%
50 97.3 4.03 115.7 4.92 134.6 5.85 144.0 6.33 150.9 6.60 154.3 6.34 157.7 6.09
53.6 97.3 4.11 115.7 5.01 134.6 5.96 144.0 6.44 148.7 6.56 152.1 6.31 155.6 6.06
57.2 97.3 4.18 115.7 5.11 134.6 6.08 144.0 6.57 146.6 6.52 150.4 6.27 153.9 6.31
60.8 97.3 4.26 115.7 5.22 134.6 6.20 143.1 6.62 144.9 6.53 148.3 6.60 151.7 6.65
64.4 97.3 4.34 115.7 5.32 134.6 6.42 141.0 6.84 142.7 6.87 146.1 6.93 150.0 7.00
68 97.3 4.43 115.7 5.53 134.6 6.89 139.3 7.18 141.0 7.20 144.4 7.27 147.9 7.33
69.8 97.3 4.47 115.7 5.72 134.6 7.14 138.0 7.35 139.7 7.37 143.6 7.44 147.0 7.51
73.4 97.3 4.78 115.7 6.13 134.6 7.64 136.3 7.67 138.0 7.71 141.4 7.79 144.9 7.85
77 97.3 5.10 115.7 6.56 132.4 7.98 134.1 8.00 135.9 8.04 139.7 8.12 143.1 8.20
80.6 97.3 5.45 115.7 7.01 130.7 8.30 132.4 8.35 134.1 8.39 137.6 8.47 141.0 8.55
84.2 97.3 5.81 115.7 7.49 128.6 8.64 130.3 8.69 132.0 8.73 135.4 8.82 139.3 8.90
87.8 97.3 6.20 115.7 7.99 126.9 8.99 128.6 9.02 130.3 9.08 133.7 9.17 137.1 9.26
91.4 97.3 6.60 115.7 8.53 124.7 9.32 126.4 9.37 128.1 9.41 131.6 9.52 135.0 9.61
95 97.3 7.02 115.7 9.09 122.6 9.66 124.3 9.71 126.4 9.76 129.9 9.86 133.3 9.97
98.6 97.3 7.48 115.7 9.68 120.9 10.01 122.6 10.06 124.3 10.11 127.7 10.21 131.1 10.33
102.2 97.3 7.95 115.3 10.23 118.7 10.34 120.4 10.41 122.1 10.46 126.0 10.57 129.4 10.68
