Gree SAPPHIRE SAP12HP230V1AH User Manual

5
Technical Information
Service Manual
The above data is subject to change without notice; please refer to the nameplate of the unit.
Outdoor Unit
Model of Outdoor Unit SAP09HP230V1AO
Outdoor Unit Product Code CB497W00200_L75973
Compressor Manufacturer/Trademark ZHUHAI LANDA COMPRESSOR CO., LTD
Compressor Model QXAT-B121zE070
Compressor Oil FV50S
Compressor Type Rotary
Compressor L.R.A. A 35.0
Compressor RLA 6.9
Compressor Power Input W 1070
Overload Protector 1NT11L-6233/HPC115/95/KSD115ºC
Throttling Method Electron expansion valve
Operation temp ºF 61~86
Ambient temp (cooling) ºF 0~129
Ambient temp (heating) ºF -22~75
Condenser Form Aluminum Fin-copper Tube
Pipe Diameter inch Φ9/32
Rows-n Gap inch 2.5-1/18
Coil Length (LXDXW) inch 30.0X2 1/4X21 7/10
Fan Motor Speed rpm 800/500
Output of Fan Motor W 30
Fan Motor RLA A 0.28
Fan Motor Capacitor μF /
Air Flow Volume of Outdoor Unit CFM 1412
Fan Type Axial-ow
Fan Diameter inch Φ17 1/4
Defrosting Method Automatic Defrosting
Climate Type T1
Isolation I
Moisture Protection IPX4
Design Pressure(High) PSIG 550
Design Pressure(Low) PSIG 240
Sound Pressure Level (H/M/L) dB (A) 57/-/-
Sound Power Level (H/M/L) dB (A) /
Dimension (WXHXD) inch 35 3/8X23 1/2X14 7/8
Dimension of Carton Box (LXWXH) inch 37 3/16X16 7/16X24 13/16
Dimension of Package (LXWXH) inch 37 5/16X16 9/16X25 3/8
Net Weight Ib 99.2
Gross Weight Ib 105.8
Refrigerant R410A
Refrigerant Charge oz 55.4
Connection
Pipe
Length ft 24.6
Gas Additional Charge oz/ft 0.2
Outer Diameter Liquid Pipe inch 1/4
Outer Diameter Gas Pipe inch 1/2
Max Distance Height ft 32.8
Max Distance Length ft 49.2
Note:The connection pipe applies metric diameter.

Gree SAPPHIRE SAP12HP230V1AH Specifications

General

Cooling Capacity	12, 000 BTU/h
Heating Capacity	12, 000 BTU/h
Refrigerant	R410A
Outdoor Unit Noise Level	52 dB(A)
Compressor Type	Rotary
Net Weight (Indoor Unit)	22 lbs
Type	Split System
Power Supply	230V, 1Ph, 60Hz
