U-Match Series Cassette Type Unit
47
5.3 Unit Maintenance
5.3.1 Clean Air Filter
If the air conditioner is used at a dusty place, clean the air filter regularly. (Once
every half a year)
How to clean the air filter
1) Open the air intake grill.
Push the clasps outward and then
open the air intake grill.
—
2) Remove the air filter.
① Remove the screws by a screwdriver
as shown in the picture.
②
Push those two fasteners and open
the panel grille.
③ Open the air inlet grille at 45°, raise it
and remove the grille.
④ Disassemble the filter screenDraw out
the filter screen and remove it.
3) Disassemble the air purifier
Remove the air purifier after removing
the fixed screws on it.
To Next Page
