5HPRYDO3URFHGXUHRI,QGRRU8QLW
:DUQLQJ
%HVXUHWRZDLWIRUDPLQLPXPRIPLQXWHVDIWHU
WXUQLQJRIIDOOSRZHUVXSSOLHVEHIRUHGLVDVVHPEO\
Procedure
Steps
a
b
1.Before disassembly
2.Remove filter sub-assy
Loosen the clasps at the left side and right side
of the panel, and then open the front panel.
Loosen the clasps of the filter sub-assy; push
the filter inwards, and then pull it upwards to
remove the filter sub-assy.
filter
clasp
panel
127(7DNH$SDQHOIRUH[DPSOH
