Gree YV1FB7 - Page 55

52
Installation and Maintenance
Service Manual
b
Remove the screws connecting the front panel with
the chassis and the motor support. Remove the front
panel.
Remove the screws connecting the rear grille with
the left side plate and the right side plate. Remove
the rear grille．
Remove the screw fixing the handle.
Remove the handle.
3.Remove the rear grille
4.Remove the handle
front panel
handle
rear grille
