5.1 Upkeep
!
Pay Attention
五、Maintenance and repair
Maintain the maintenance schedule
Charger
When charging, first connect the output plug of the charger with the charging
socket of the batter y, then connect the input plug of the charger to an AC power
supply of 220V. The Red light on the charger indicates normal connection with the
power supply.
When the charger is connected to the power supply to charge the battery, the
charging indicator shows a red state, indicating that the battery is in a state of
constant current charging. When the charger turns to a green state, the battery
capacity is basically 100% full, if the battery continues to charge, the charger enters
to carr y on the micro-current supplement to the battery.
When charging should turn off the vehicle power switch, pull up the parking
handle, unplug the car keys, in order to prevent accidental factors make the vehicle
suddenly start.
After charging, should first unplug the plug, and then unplug the plug connected
to the battery, is strictly prohibited in the case of non-charging, for a long time to
connect the charger to the AC power supply.
Security alert
1.Chargers should be used and stored to prevent the infiltration of liquid
and metal debris into the charger, in order to prevent the charger internal
short circuit damage charger.
2.Must use this car equipped with the charger to charge, do not mix the
charger and battery must match to use, do not charger wires and other wires
winding, mopping, trampling, so as to avoid short-circuit or other accidents.
3. Check whether the charger light will turn“Green” when charging. In
case of abnormality, the power should be cut off immediately, and the
batter y and charger together to repair and check, prohibit private
disassembly of the charger for maintenance, to avoid electric shock.
4.When carr ying the charger, must not violent bump or collision,
otherwise easy to cause damage.
5.It is strictly forbidden to charge the battery at night after rest without
anyone looking after it. It is strictly forbidden to be too close to people's
living environment when charging, and to place inflammable and explosive
materials and gases around it, otherwise it may cause fire and other
accidents.
6.must be in a well-ventilated and well-cooled environment charge, do
not charge in a narrow, closed space, do not cover the charger, battery box
on and around the top of any items.
7.the charger in the process of work will produce a certain amount of
heat, the bottom of the charger is prohibited to place flammable and
explosive items, such as flammable plastic or foam, etc. . If you smell a
strange smell during charging or find that the case of the charger is too hot
(the surface temperature of the case is over 65 ° C) , please stop charging
immediately and send it to the Maintenance Department for Inspection and
disposal.
5.1 Storage Battery
Maintenance cycle is based on the mileage of the maintenance period, is the
implementation of regular maintenance and lubrication of the guiding basis. If the
car is being driven at high speed for long periods of time under harsh conditions, it
must be serviced more frequently. If the thunderbolt is undergoing major repairs or
has had a crash, then must ask the maintenance department personnel to carefully
check the thunder King Electric Car's main components repair or replacement has
been displaced or damaged parts, to ensure safe driving effect.
(1) The rear axle needs to change gear oil every 2000 km;
(2)Open the bolt to flow out the gear oil and tighten the bolt, open the bolt and
pour into the gear oil (85W/90gl-4) about 150 ml, then tighten the bolt after
refueling.
(3)Motor should try to avoid contact with water, not in the higher water.
Oiling port
Oil Drain
Vehicles should be in accordance with the provisions of maintenance and
maintenance, so that you can ensure the safety of driving, but also extend the life of
the vehicle. If you need service, please send your vehicle to our special service
center.
Projects
The mileage or time of maintenance
Content
Steering bearing
Brake gear
Fasteners
Tires
Storage Battery
Motor
Per 1,000 km
Per 1,000 km
Per 1,000 km
Monthly
Monthly
Monthly
Check and adjust
Check and lubricate
Check and adjust
Check and tighten
Check and clean
Check
In order to ensure the safety and reliability of the thunder King Electric
Vehicle, it is not allowed to change the original parts of the company or the
same parts of the same quality when the thunder King Electric Vehicle is
refitted, repaired or maintained. If the use of other quality parts, will affect
the performance and operation of electric vehicles.
