ASSEMBLY
STEP 1: REMOVE CARTON PACKAGING
STEP 2: REMOVE AND CHECK COMPONENTS AND ACCESSORIES
1. Drive wheels (x2)
2. Plough discs (x2)
3. Left blades (x3)
4. Right blades (x3)
5. Puncher (x1)
6. Drive belt protection (x1)
7. Support + Depth limiter (x1)
8. Fins protection fastening (x1)
9. Shift lever (x1)
10. Front transport wheel (x1)
11. Right wing protection (x1)
12. Left protection ap (x1)
1
2
6
3
4
7
10
8
9
11
12
5
2
