1. Rubber washers M8x20 (x10)
2. M8x20 (x8) screws
3. Nut M8 (x8)
4. Battery (x1)
5. Screw M5x10 (x2) + nut M5 (x2)
6. Shift lever (x1)
7. Battery base protector (x1)
8. Battery connection cables (x1)
9. Battery xation (x1)
10. Spark plug wrench (x1)
11. Mounting Keys 8/10-12/14-13-13/16-17/19
12. Nuts M8 (x8)
13. Nuts M5 (x6)
14. User manual (x1)
15. Allen keys nº 4 and 5 (x1)+(x1)
16. Combination screwdriver (x1)
17. Nut m5 (shift lever) (x1)
18. M6x20 (x6) screws
19. M6x16 (x4) screws
20. M6x16 (x2) screws
21. Knife xing pins 8x50mm (x2)
22. Nylon Clamps (x5)
23. Screws M8x55 (x2)
24. Screw (shift lever) M5x20 (x1)
25. Washers 8x24mm (x6)
26. Washers 6x18mm (x6)
27. Battery mounting screws M6x90 (x2)
• Carefully remove the product and accessories from the box. Make sure all the items listed above are present.
• Inspect the product carefully to make sure it has not suffered any breakage or damage during transport.
• Do not discard the packaging material until you have thoroughly inspected the product and used it satisfactorily.
ATTENTION: If any part is missing or damaged, contact the GREENCUT technical service. Do not
use this product without having replaced the part. Using this product with damaged or missing parts
can cause serious injury to the operator.
