8
Test Table
To test/verify … connect the fixed connect the removable and the tester
probe to … probe to … will indicate
Continuity * component or circuit component or circuit tone for resistance
under test under test of 0 to 800 kΩ
(approximately)
Hot Conductor* hot or live N/A tone for voltage of
conductor 100 to 690 V AC
Neutral Conductor* neutral conductor N/A no indication
Voltage (AC) component or circuit component or circuit voltage of
under test under test 12 V or greater
Voltage (DC) component or circuit component or circuit voltage of 12 V
under test under test or greater,
plus polarity
* Unit must be charged up for at least 5 seconds on 100 V or more. Unit will maintain charge
for 30 seconds of use or 30 minutes of standby.
