Greenlee Textron / Subsidiary of Textron Inc.
11
4455 Boeing Dr., Rockford, IL 61109-2988 815/397-7070
690 and 690-22 Power Fishing System
Parts List — 690 and 690-22
CAT. NO.
KEY 78-3310- PART NO. DESCRIPTION QTY.
503 4392.0 Tank Assembly (includes items 1–8, 44–46) ... 1
1 503 4394.7 Tank Unit without Wheels................................. 1
2 905 2738.0 Swivel Caster.................................................... 2
3 905 4118.9 Washer ............................................................. 4
4 905 3808.0 Screw, #12-24 x 5/8 Rd. Hd. Mach. ................. 4
5 503 4030.1 Axle Bracket ..................................................... 1
6 503 4031.0 Axle ................................................................... 1
7 905 1353.3 1/2" Retaining Ring........................................... 4
8 905 2737.2 Rubber Wheel................................................... 2
9 905 4811.6 Nut, Push-on..................................................... 6
500 0501.4 Vacuum Unit Assembly (115 Volt)
500 0500.6 Vacuum Unit Assembly (220 Volt)
(includes items 10–28A, 43, 47–51)
10 503 1325.8 Vacuum Motor and Blower (115 Volt) .............. 1
503 1342.8 Vacuum Motor and Blower (220 Volt)
11 503 1773.3 Power Cord (must be modified
for 220 Volt with item 49).................................. 1
12 918 5284.6 Power Switch with Nut...................................... 1
13 905 2434.9 Nut, 8–32 .......................................................... 2
14 500 0423.9 Switch Plate ...................................................... 1
15 500 0422.0 Air Baffle ........................................................... 1
16 905 1649.4 Washer, Internal Tooth ..................................... 2
17 905 3936.2 Self-tapping Screws ......................................... 4
18 905 1669.9 Nut, 1/4–20 Nylock ........................................... 3
19 905 1532.3 Screw, 8–32 x .5 ............................................... 1
20 500 0907.9 Rainhat and Decals (115 Volt) ......................... 1
500 0995.8 Rainhat and Decals (220 Volt) ......................... 1
503 2118.8 Tank Cover and Motor Mount
(includes items 9, 21–28A) ............................... 1
21 500 0906.0 Tank Cover ....................................................... 1
22 503 8814.2 Gasket, Blower ................................................. 1
23 501 6667.0 Gasket, Tank .................................................... 1
24 501 6669.7 Ball Valve.......................................................... 1
25 500 0504.9 Filter Basket...................................................... 1
26 905 2125.0 Washer ............................................................. 3
27 905 4812.4 Hex Hd. Bolt 1/4–20 x 2.25 .............................. 3
28 503 1314.2 Filter Bag, Inner ................................................ 1
28A 503 1315.0 Filter Bag, Outer ............................................... 1
29 503 8624.7 Flexible Hose, 1-1/2" dia. x 10 ft. ..................... 1
30 503 2104.3 Flexible Hose, 1-1/2" x 1 ft. .............................. 1
35 595 85 lb Tensile Strength Nylon Line (2150 ft)...... 1
36 502 5646.7 Adapter Cone 1/2" to 1".................................... 1
37 502 5644.0 Adapter Cone 1-1/4" to 2-1/2" .......................... 1
38 502 5645.9 Adapter Cone 3" to 4"....................................... 1
40 502 3360.2 Adapter Nozzle for Tape and Line ................... 1
