Greenlee 690 - Operation

Greenlee Textron / Subsidiary of Textron Inc.
7
4455 Boeing Dr., Rockford, IL 61109-2988 815/397-7070
690 and 690-22 Power Fishing Systems
Operation (cont’d)
VACUUMING
Line Tied
to Piston
Piston
Nose
Cone
Fish Line
Cannister
Line Drag Insert
Adapter
Cone
CAUTION
1
3
2
Cone 1-1/4" to 2-1/2"
Cone 3" to 4"
Cone 1/2" to 1"
Washer 5" and 6"
(optional)
Adapters
CAUTION
1
3
2
BLOWING
BLOWING WITH OPTIONAL 592 MIGHTY MOUSER
®
