Identification
1. Display
2. Selector
3. Lever
4. Jaw
5. HOLD button
6. Common (COM)
input terminal
7. Volts or resistance
(V-Ω) input
terminal
8. Battery cover
9. Battery cover
screw
Symbols on the Unit
Warning—Read the instruction manual
Double insulation
Battery
5
6
4
2
1
7
3
9
8
Front
Back
Display Icons
10. – Polarity indicator
11. Hold function is enabled
12. Low battery indicator
13. Overload indication
11
10
12
13
