Greenlee DVC-6 - Operation Details and Test Table; Test Procedures and Connections; Test Indications and Results

8
Operation (cont’d)
Test Table
*DVC-10 also displays voltage on LCD.
To test/verify …
connect the connect the and the tester
fixed probe to … removable probe to … will indicate
component component tone for resistance
Continuity or circuit or circuit of 0 to 1 MΩ
under test under test (approximately)
Hot Conductor
hot or live
N/A
tone for voltage
conductor of 100 to 600 V AC
Neutral Conductor neutral conductor N/A no indication
Voltage (AC) component or circuit component or circuit voltage of 12 V
(DVC-6) under test under test or greater
Voltage (AC) component or circuit component or circuit voltage of 120 V
(DVC-10) under test under test or greater*
Voltage (DC)
component component voltage of 12 V
(DVC-6)
or circuit or circuit or greater,
under test under test plus polarity
Voltage (DC)
component component voltage of 120 V
(DVC-10)
or circuit or circuit or greater,
under test under test plus polarity*
Press flashlight
GFCI hot or live conductor earth ground button on back of
case to test GFCI.
