11
ASSEMBLY
ASSEMBLING THE HANDLEBAR (See Figure. 3)
• Align the holes on the middle with the holes on the lower handles. Insert the bolts, and
tighten them using the wing nuts provided.
• Fold the handle base on the Fig.4 - 4.1
Step1: Release the wing nuts
Step2: Rotate the upper handle
base on the arrowhead 1
way (See Fig 3)
Fig. 3
Fig. 4.1
Fig. 4
LOWER HANDLE
UPPER
HANDLE
ARROWHEAD 1
WING NUT
