KNOW YOUR CULTIVATOR
Read this operator’s manual and safety rules before operating your cultivator. Compare the
illutration in Fig.2.1 to your cultivator in order to familiarize yourself with the location of various
controls and adjustments. Save this manual for future reference.
Fig. 2
SAFETY LOCK-OUT BUTTON
HANDLEBAR
TINE SHIELD
RING PIN
OUTER TINES
WHEEL ASSEMBLY
INNER TINES
BALE SWITCH
PLUG CONNECTOR
BOLT
HITCH PIN
