ASSEMBLY
ADJUSTINg THE CUTTIN g SWATH (See Figure 5.)
The trimmer is currently set at a 14 in. cutting swath. To adjust to a cutting swath of 16 in.:
• Remove the battery from the string trimmer.
• Remove both screws on the cut-off blade with a Phillips screwdriver (not included).
• Rotate the cut-off blade 180°.
• Replace both screws in the cut-off blade.
Note: Set the cut-off blade to 14 in. for greater runtime. Set the cut-off blade to 16 in. for greater
cutting area.
CUT-OFF BLADE
ATTACHINg A SHOULDER HARNESS (See Figure 6.)
• Rotate the harness holder to the upward position.
• Hook a shoulder harness (not included) to the harness holder.
HARNESS HOLDER
Fig. 5
Fig. 6
12
