8
KNOW YOUR STRING TRIMMER
AUXILIARY HANDLE
The string trimmer is equipped with an auxiliary handle for ease of operation and to prevent loss
of control.
gUARD
The trimmer includes a guard that helps protect you from ying debris.
KNOW YOUR STRINg TRImmER (See Figure 1.)
The safe use of this product requires an understanding of the information on the product and in
this operator’s manual as well as a knowledge of the project you are attempting. Before use of this
product, familiarize yourself with all operating features and safety rules.
Fig. 1
REAR HANDLE
HIgH/LOW SPEED
BUTTON
ON/OFF BUTTON
SWITCH TRIggER
AUXILIARY HANDLE
COUPLER
TRImmER SHAFT
gEAR HEAD
gUARD
TRImmER HEAD
LOCK-OUT BUTTON
