1 DESCRIPTION
1.1 PURPOSE
The product fitted with a cutting attachment mounted
on a pole to enable the operator to cut the branches
of standing trees but not intends for cutting woods as
normal chainsaw.
This appliance is not intended for use by persons
(including children) with reduced understanding, or lack
of experience and knowledge, unless they have been
given supervision or instruction concerning use of the
appliance by a person responsible for their safety.
Children should be supervised to ensure that they do
not play with the appliance.
1.2 OVERVIEW
Figure 1-20
1
Small lock-out
button
2
Lock-out button
3
Trigger
4
Pole saw handle
5
Collar
6
Extension pole
7
Pole saw head
8
Chain cover lock
nut
9
Oil tank cap
10
Bar
11
Chain
12
Oil indicator
13
Chain lubricant
14
Chain cover
2 GENERAL POWER TOOL
SAFETY WARNINGS
WARNING
Read all safety warnings and all instructions.
Failure to follow the warnings and instructions may
result in electric shock, fire and/or serious injury.
Save all warnings and instructions for future
reference.
The term "power tool" in the warnings refers to your
mains-operated (corded) power tool or battery-operated
(cordless) power tool.
3 INSTALLATION
3.1 UNPACK THE MACHINE
WARNING
Make sure that you correctly assemble the machine
before use.
WARNING
• If parts of the machine are damaged, do not use
the machine.
• If you do not have all the parts, do not operate the
machine.
• If parts are damaged or missing, contact the
service center.
1. Open the package.
2. Read the documentation provided in the box.
3. Remove all the unassembled parts from the box.
4. Remove the machine from the box.
5. Discard the box and packing material in compliance
with local regulations.
3.2 ADD THE BAR AND CHAIN OIL
Examine the amount of oil in the machine. If the oil level
is low, add the bar and chain oil as follows.
IMPORTANT
Use bar and chain oil that is only for chains and chain
oilers.
NOTE
The machine comes from the factory without bar and
chain oil.
1. Loosen and remove the cap from the oil tank.
2. Put the oil into the oil tank.
3. Monitor the oil indicator to make sure that no dirt
enters in the oil tank while you add the oil.
4. Put the oil cap on.
5. Tighten the oil cap.
6. A completely filled oil tank will last for 15 - 40
minutes operating time.
IMPORTANT
Do not use dirty, used or contaminated oil. Damage
can occur to the bar or chain.
3.3 FIT THE POLE SAW
Figure 2-3
1. Mount the pole saw head on pole saw handle to
achieve the standard length.
2. Slide the collar upwards.
3. Turn the collar clockwise to tight it.
3.4 EXTENSION OF THE POLE SAW
Figure 2-3
4
English
EN
