17
mismatch
GFCI Mismatch The GFCI value of Master and Slave are mismatch
DC Curr Mismatch The Output DC current of Master and Slave are
mismatch
Message table in English
Operating conditions
Display
message
Description
Normal working status
Power off No display
PV inverter is totally shutdown, IPV
<=90V.
Standby INV Standby 90V< Input voltage < =100V.
Initialization & waiting INV Waiting
Input voltage range 100~150V
during start-up. After PV voltage is
higher than 100V, inverter is waiting
for feeding to grid.
Check grid Testing
When PV voltage> 150V, inverter is
checking feeding conditions.
Feeding grid, MPPT Working Mode Inverter is feeding power.
Updating Master CPU firmware Master Flash
The internal program is updating
Master CPU through RS232
interface.
Updating Slave CPU firmware Slave Flash
The internal program is updating
Slave CPU through RS232 interface.
Monitoring parameters
Instantaneous Output power
O/P
Watt=xxxxW
The real time output power in xxxx
W.
Accumulated energy information xxxxx KWh
Total energy which has been feed to
grid since inverter was installed.
Grid voltage
GRID
VOLT=xxx.xV
Grid voltage in xxx.x VAC.
Grid frequency
GRID
FREQ=xx.xHz
Grid frequency in xx.x Hz.
AC feeding current
O/P
CUR=xx.xA
AC grid current amount in xx.x A.
PV panel voltage
PV
VOLT=xxx.xV
Input voltage from PV panel, xxx.x
VDC.
System fault
Isolation failure Isolation Fault
Earth fault of the PV-panels or
failure of surge voltage protection.
GFCI
(Ground Fault Current Interrupter)
active
Ground I Fault
Current on ground conductor is too
high.
