22
7. Specification:
Model 1500 2000 3000 4000 6000
Output power 1500W 2000W 3000W 4000W 6000W
Maximum power 1650W 2200W 3300W 4400W 6000W
Input
Nominal DC voltage 360 VDC
Maximum PV open
voltage
500 VDC 600V
MPPT range 200 to 400V +/-5% 150 to
600V+/-5%
Working range 100 to 500VDC 100 to
600VDC
Max. input current 7.5ADC 10ADC 15ADC 20ADC 25ADC
Output
Operational voltage 230VAC
Operational
frequency
50/60Hz, auto selection
Current distortion < 3%
Power factor > 0.99
Conversion efficiency
(max)
>94% >95% >95% >96% >96%
European efficiency >93% >94% >94% >95% >95%
Environment
Protection degree IP 65
Operation
temperature
-25 to 55ºC, output power derating at 40 °C and higher
Humidity 0 to 95%, non-condensing
Heat Dissipation Convection
Acoustic noise level <40dB,A-weighted.
Communication & features
Comm. Interface RS232 standard, USB, SNMP & RS485 optional
F/W upgrade Yes, via RS232
Mechanical
W×D×H (mm)
352x300x133 352x300x133 352x300x143 550x300x133 550x420x143
Weight (kg) 14 14 14 21 27
∗The product’s specifications are subject to change without notice.
