9
1500 2000 3000 4000 6000
W (mm)
347.6 347.6 347.6 546
546
H (mm)
257 257 257 257
327
4. Drill the holes with screw.
5. Hang the inverter on the 4 screws.
6. Drive “fix screw” on bottom leg to fix the inverter.
Be sure to check the mounting of inverter. Try to lift up the inverter on the
bottom, make sure it is firmly attached.
Select the installation location carefully. The height of inverter is
recommended to be seeable, so that user can check the inverter status
