14
ADJUSTING THE CUTTING DECK
A level deck is essential for a uniform cut over the whole lawn.
With the mower on a flat surface, check that the tyre pressure is correct, check the float spring tension, and if
necessary turn the adjuster screw (fig. 7 “D”).
If a satisfactory parallel setup cannot be achieved, adjust the register n° 14 fig. 2.
To adjust the mowing height, set the lever n° 6 fig. 1/B on the lowest setting, fit two 30 mm shims at the sides
under the edge of the deck and set the wire fig. 2 and 2/A n.12 taut.
Every 20 hours lubricate with fat the front wheels pins.
DRIVE BELTS - HYDROSTATIC AXLE
These belts are self-adjusting and do not require any adjustment, Simply check the spring tension, to replace
the belts, release the tension spring (fig. 14 “G”).
PTO BELT
Caution! This belt is special, use only original belts.
To replace, proceed as already explained for replacement of the engine-hydrostatic axle belt (upper springx fig.
14 “G”):
1) Remove the guard above the deck by unscrewing the two screws fig. 2 n° 13.
2) Remove the pin bolt fig. 12 “E”.
3) Turn the lever clockwise fig. 12 “C”.
4) Remove the PTO belt fig. 12 "F".
The PTO belt does not have to be adjusted as it is self-adjusting.
TROUBLESHOOTING GUIDE:
PROBLEM
With the key in the ON position, the instrument panel remains off - PETROL ENGINE
– Battery not supplying any power – Check the connecting leads
– Charge the battery
– Change the fuse
The instrument panel comes on, but with the key in the ON position, the starter motor does not turn
– Battery not supplying enough power – Charge the battery
– Start-up not enabled – Travel pedal in STOP position
– Disengage the blades
– Sit in the driving seat
Engine difficult to start or runs unevenly
– Carburettor problems – Clean or replace the air filter
– Adjust the carburettor (refer to the motor handbook)
– Sediment or dirt in the fuel – Empty the tank and use fresh petrol
– Check the fuel filter and replace if necessary
The starter motor turns but the engine will not start
– No petrol flow – Check that the choke is on (if the engine is cold)
– Check level in tank
– Check the fuel filter and replace if necessary
– Check that the fuel cap bleeder hole
is not blocked
– Ignition system fault – Check that the spark plug cap is on properly
– Check that the electrodes are clean and the
gap is correct
CAUSE REMEDY
