Translation of the original instructions
A set of electrical equipment fuses
HOW TO ORDER SPARE PARTS
Always state the machine serial number and the code of the spare part needed. Contact our service centres. Our
address is:
GRILLO S.p.A.
Via Cervese 1701 – 47521 CESENA (FC) ITALY
Tel. 0039 – 0547 – 633.111 / Fax 0039 – 0547 – 632.011
Web site: www.grillospa.it / e-mail: grillo@grillospa.it
TECHNICAL SPECIFICATIONS
MODEL: hydrostatic lawnmower with front cutting deck.
ENGINE: YANMAR 3TNV76 Diesel 1116 cc (26 HP @ 3000 r.p.m.) 3 cylinders liquid-cooled with
electric valve, provided with manual and automatic device for radiator cleaning.
FUEL TANK: 31 litres.
HYDRAULIC OIL TANK: 6,3 litres.
STARTER: electric 12V.
TRACTION: hydraulic traction with 4 driving wheels (permanent integral traction also on tight turning
radius).
AUTOMATIC DIFFERENTIAL LOCK AND MANUAL WITH PUSH BUTTON.
GEARBOX: hydrostatic transmission with 4 hydraulic engines on the 4 wheels.
STEERING SYSTEM: hydraulic drive with steering wheel.
CLUTCH: electromagnetic for PTO, with magnetic blade brake.
SPEED: from 0 to 14,5 km/h continuously variable.
WHEELS front: 23x 10.50-12 TURF WHEELS; rear: 18×7.50-8 TURF WHEELS.
SEAT: Grammer super comfort and adjustable sprung seat. With side steel protections.
STEERING WHEEL: fixed on steering column and adjustable.
TURNING RADIUS: 370 mm.
AUTOMATIC FEATURES: automatic disengagement of blades when the grass catcher is full.
BRAKE: drum service and parking brakes.
GRASS CATCHER: 750 litres. Automatic opening with hydraulic discharge.
DISCHARGE HEIGHT: 1950 mm REAR PROJECTION: 300 mm
MOTORISED BAFFLE PROVIDING FULL AND EVEN GRASS CATCHER FILLING.
HYDRAULIC CUTTING DECK LIFTING AND GRASS CATCHER DISCHARGE
CUTTING DECK: with collection
CUTTING HEIGHT: from 20 to 100 mm, hydraulic and continuously adjustable from the driving
position.
CUTTING WIDTH: 126 cm.
HOURLY MOWING CAPACITY: 9.000 m²/h.
ROAD HOMOLOGATION LIGHTS: as a standard feature.
ATTACHMENTS: 126 cm (± 52 in) cutting deck with collection.
SIZE (with cutting deck): Length: 2910 mm - Width: 1330 mm - Height: 1660 mm
GROUND CLEARANCE: 150 mm
DISTANCE BETWEEN AXLES: 1190 mm
WEIGHT (without cutting deck): 795 kg - WEIGHT (with cutting deck): 970 kg
