IDENTIFICATION AND AFTER- SALES SERVICE
IDENTIFICATION
AFTER-SALES SERVICE
This handbook provides instructions for the use of the lawn-mower and for correct basic servicing which
the user can carry out himself.
For all procedures not describede in this handbook, contact your local dealer.
The vehicle’s serial number is punched on the nameplate on
the left- hand longitudinal member of the chassis and on the
gearbox nameplate.
Always state the serial number when ordering spare parts.
Grillo GF2
tipo
serie
massa c.a.
anno
KW/giri minuto
S.p.A.
CESENA - ITALY
TECHNICAL DATA
ENGINE TYPES:
ROBIN EX17
LOMBARDINI 15LD225
MACHINE:
Clutch: dry, manually controlled.
Gearbox: 6-speed - 3 forward + 3 reverse gears.
Forward speed with the engine running at 3600rpm is as follows (in km/h):
P.T.O.: at 965rpm independent of the gear change with the motor running at 3600rpm..
Wheels: 4.00-8 … antidrift tyres - 16x6.50-8 tyres.
Cutter bar: central cutter bar 97 - 110 - 115 cm.
Handlebar: side and height adjustment in several positions.
Track: measured from the outer edge of the wheels: with 4.00-8 tyres 43 cm.
Implements and accessories: cutter bar, snowthrower, cage wheels with antidrift rings, side cutter bar
guard, wheel extensions, twin wheels, rotary tiller 58 cms, grass cutter cm. 50, spraying unit complete with
pump, single furrow ploug, adjustable furrower.
INSTRUCTION FOR USE
PUTING THE MACHINE INTO SERVICE
1) Check that the machine has not been damaged in transit..
2) Fill with grease the machine PTO flanging all around the coupling
3) Select driving handlebar position according to the use, Walking tractor or Motormower.
4) Mount wheels and implement.
5) Add engine oil, please refer to attached instruction booklet.
6) Check gearbox oil (fig. 4) use MP 80W 90 oil, or international equivalent API GL5 oil, US MILL-2105D, quantity
2,2 litres.
7) Insert the control levers.
GEAR SPEED 4.00-8 WHEELS
1st 1,1
2nd 2,6
3rd 4,3
1
st
rev. 1,1
2
nd
rev. 2,6
3
rd
rev. 4,3
