CS Espresso Machine Grindmaster
®®
5
Overview continued
CS3
Control Panel
Figure E
Figure F
Figure G
1 Espresso brewing unit control panel 11 Cup rack
4 Hot water wand 12 Sight glass (Boiler level check window)
5 Steam knob 14 Steam boilder pressure gauge
6 Steam wand 15 Pump pressure gauge
7 Main switch 17 Drain tray
8 Brewing group 18 Leg
9 Porta Filter 20 Hot water knob
Small single portion
Small double portion
Large single portion
Large double portion
Continuous Flow Button
