Grizzly G0528 Instruction Manual

-8-
G0528 Sliding Router Table
A. Left Fence .....................................................1
B. Right Fence ...................................................1
C. Dust Hood .....................................................1
D. Power Cord ...................................................1
E. Switch ............................................................1
F. Switch Box .....................................................1
G. Workpiece Hold-Downs .................................2
H. Miter Plate .....................................................1
I. Miter Fence ...................................................1
J. Router Clamps ..............................................4
K. 29MM Table Insert ........................................1
L. 60MM Table Insert ........................................1
M. Fence Lock Handles ......................................2
N. Hardware Bag
— Rubber Stops .........................................2
— Phillips Screws
1
⁄4"-20 x 1
1
⁄2" ..................2
— Flat Washers
1
⁄4" .....................................4
— Hex Nuts
1
⁄4"-20 ......................................2
— Hex Bolts
5
⁄16"-18 x 1" .............................2
— Hex Nuts
5
⁄16"-18 .....................................4
Figure 3. G0528 Inventory.
— Flat Washers
5
⁄16" ....................................8
— Cap Screws
5
⁄16"-18 x 1
1
⁄2" ......................2
— Spacers ..................................................2
O. Hardware Bag
— Carriage Bolts
5
⁄16"-18 x
1
⁄2" ...................32
— Flat Washers
5
⁄16" ..................................32
— Lock Washers
5
⁄16" ................................32
— Hex Nuts
5
⁄16"-18 ...................................32
— Rubber Feet ...........................................4
— Phillips Screws
1
⁄4"-20 x 1" .....................4
— Flat Washers
1
⁄4" .....................................4
— Hex Nuts
1
⁄4"-20 ......................................4
P. Diagonal Supports ..........................................2
Q. Stand Legs ....................................................4
R. Cross Supports ..............................................4
S. Strain Relief ...................................................1
DESCRIPTION QTY
DESCRIPTION QTY
A
B
C
E
D
F
G
P
Q
R
H
I
J
K
L
M
N
O
G0528 Inventory
