4
Maintenance
Shut off cold and hot water supplies.
Inspect and clean all components and replace if necessary.
I. Battery
Batteries which are almost discharged are indicated by a
flashing indicator lamp.
1. Fit cleaning clip (K), see Fig. [7].
2. Unscrew and remove screw (L) and remove housing (M),
see Fig. [8].
3. Pull off protective sleeve (N) and take out battery (O), check
contacts, clean and if necessary replace.
Assemble in reverse order.
II. Solenoid valve
1. Proceed as for maintenance of battery, points 1 to 3.
2. Unscrew and remove screws (P1) and pull out battery
tray (P), see Fig. [9].
3. Detach plug-in connector (R) and remove solenoid valve (S)
by turning clockwise (left-hand thread) using a 5mm allen
key, see Fig. [10].
4. Remove filter (T).
Install in the reverse order, note installation position.
III. Filter
1. Unscrew connention hose and remove adapter (C), see
Fig. [11].
2. Remove filter (B).
Assemble in reverse order.
IIV. Remove and clean mousseur (13 943)
Assemble in reverse order.
V. Mixer spindle
1. Disconnect fitting from connections.
2.Remove fitting from wash basin. Disassembly is as
described in section Setting temperature limiter, see
Figs. [5] and [6].
3. Remove screw (U) from housing using a 2.5mm allen key,
see Fig. [12].
4. Pull out mixer spindle (G).
Assemble in reverse order.
Screw (U) must engage in groove (G1) of mixer
spindle (G).
Replacement parts
see fold-out page I (* = special accessories)
Care
For directions on the care of this fitting, refer to the
accompanying Care Instructions.
Disposal note
Dispose of batteries in accordance with national
regulations.
Fault / Cause / Remedy
Fault Cause Remedy
Water not flowing • Water supply interrupted - Open shut-off valves, service valves
• Filter upstream of solenoid valve blocked - Clean, see “Solenoid valve maintenance”
• Solenoid valve defective - Replace, see “Solenoid valve maintenance”
• Plug-in connector of solenoid valve without
contact
- Attach plug-in connector
• Battery discharged - Replace, see “Battery maintenance”
• Hands not in reception range - Hold hands directly under the spout
Indicator lamp
flashing
• Battery almost discharged - Replace, see “Battery maintenance”
Water flows
continuously
• Solenoid valve defective - Replace, see “Solenoid valve maintenance”
Undesired water flow • Detection range of sensor system set too
high for local conditions
- Reduce range using remote control (special
accessory, Prod. no. 36 206)
Water quantity too low • Filter or mousseur dirty - Replace, see maintenance Filter (III) and
Mousseur (IV)
• Service valves not fully open - Fully open shut-off valves, service valves
• Water supply restricted - Check supply lines, open service valves
Incorrect mixed
temperature
• See “Water quantity too low”
• Limescale on mixer spindle - Clean, see “Mixer spindle maintenance”
• Incorrect setting of temperature limiter - Adjust, see “Setting the temperatur limiter”
