Fold out pages:
Application
Prod. No. 36 093:
Single-hole mixer suitable for:
• Direct connection to cold water supply
• Connection to outlet of upstream mixed water supply
Prod. No. 36 092 and 36 094:
Can be used in conjunction with:
• Pressurised storage heaters
• Thermally controlled instantaneous heaters
• Hydraulically controlled instantaneous heaters
Operation with unpressurised storage heaters (displacement
warm heaters) is not possible.
Save notes
• Installation is only possible in frost-free rooms.
• Use only genuine replacement parts and accessories.
The use of other parts will result in voiding of the warranty
and the CE identification.
Technical data
• Flow pressure min. 0.5 bar / recommended 1 - 5 bar
• Operating pressure max. 10 bar
• Test pressure 16 bar
If static pressure exceeds 5 bar, a pressure-reducing valve
must be fitted.
Avoid major pressure difference between hot and cold water
supply.
• Flow rate at 3 bar flow pressure: Approx. 6 l/min
• Temperature
Hot water inlet: max. 70 °C
Recommended (energy saving): 60 °C
• Voltage supply: 6 V-lithium battery (type CR-P2)
• Automatic safety shut-off
(factory setting): 60 s
• Run-on time (factory setting): 1 s
• Reception range with Kodak Gray Card, grey page,
8 x 10”, landscape, 5cm under the spout
(factory setting): Approx. 15cm
• Type of protection: IP 59 K
• Battery check: Flashing signal
• Water connection cold - right
hot - left
The test for electromagnetic compatibility (interference
emission test) was performed at the rated voltage and rated
current.
Special accessory
• Infrared remote control (Prod. no. 36 206) for changing the
factory settings and selecting special functions.
Approval and conformity
The conformity declarations can be obtained from the following
address:
GROHE Deutschland Vertriebs GmbH
Zur Porta 9
D-32457 Porta Westfalica
Installation
Flush piping system prior and after installation of fitting
thoroughly (Consider EN 806)!
Fitting
Refer to the dimensional drawings on fold-out page I.
Lift rod (A) must be inserted into the mixer body during
installation, see fold-out page II, Fig. [1].
Fasten fitting to wash basin, see Figs. [1] to [3].
Connection
The cold water supply must be connected on the right, hot
water supply on the left.
In order to ensure permanent, trouble-free operation, fitting of
the enclosed adaptor is mandatory.
Insert filter (B) and screw adaptor (C) together with seal (C1)
onto the service valve, see Fig. [4].
Open cold and hot-water supply and check connections
for water-tightness.
Setting the temperature limiter
Prod. No. 36 092 and 36 094:
1. Remove screw (D), see Fig. [5].
2. Turn mixer lever (E) clockwise until the desired maximum
temperature is reached.
3. Detach mixer lever (E), see Fig. [6].
4. Detach stop ring (F) and reattach with notch (F1) pointing
vertically upwards.
5. Turn mixer spindle (G) anti-clockwise to the stop.
6. Attach mixer lever (E) in horizontal position and fasten with
screw (D).
Operation
The infrared-electronic system emits invisible, pulsed light.
T
he infrared-electronics are adjusted so that water flow is
initiated when the hands approach the vicinity of the spout.
When the hands are withdrawn from the vicinity of the spout,
water flow is stopped after 1 s (factory setting).
The range of the sensor system is dependent upon the
reflective properties of the detected object.
Automatic safety shut-off
After 60 s (factory setting) of continuous detection of an object,
the infrared electronics automatically stop the water flow.
Automatic flushing (factory setting: not activated)
The automatic flushing serves to maintain water hygiene in the
case of long-term non-utilisation of the fitting. It activates water
flow for 1 - 10 minutes, 1 or 3 days after the last use.
Safety notes:
- Ensure free draining in the case of activated automatic
flushing.
- For automatic flushing of the hot and cold water lines, the
fitting must be in the mixed water setting.
Cleaning
For cleaning purposes, the fitting can be switched off by
attaching the enclosed cleaning clip (K), see Fig. [7].
This product conforms to the requirements of the
relevant EU guidelines.
