Installation must be performed in compliance
with applicable local construction and plumbing
regulations. If in doubt, contact GROHE or an
expert. The safety device within the fitting
protects the drinking water quality and must not
be modified and should only be replaced by an
expert.
Before changing the fitting switch off main shut-
off valve.
The installation of the S connector can be
challenging. To avoid damage to the piping, we
recommend that an expert perform this task.
CAUTION!
Do not overtighten the screw connections, even
with the seal inserted, to avoid damage.
Thermostats must be installed with the
adjustment in temperature at 38°C to meet the
necessary safety-related requirements.
Temperature end stop
If the termperature end stop is at 43°C, insert
accompanying temperature limiter in
temperature selection handle.
Check at regular intervals to make
sure that the installation is not leaking.
If temperature connections are reversed (hot on
right - cold on left) the thermostatic compact
catrridge needs to be replaced. A qualified
expert is recommended for this.
To avoid tile damages, we recommend drilling
into the joint. Tiles can additionally be protected
with suitable adhesive tape.
Before drilling, ensure no pipes or electric cable
running behind the wall at the corresponding
location.
