Twist the bare wire together and trimm it
with a cung tool so that when it is inserted
into the plug it is not exposed and does not
cause bad contact with other cables.
To remove a wire from the plug, use a pin to
press the hole associated to each cable
located at the surface of the plug. Finally, pull
the cable out of the hole to remove it.
Connect your actuators (OUTPUTS) in the
following order, respecng the posion of the
plug:
