EC PHTEMP
3
4
5
16
Connect the water temperature sensor (16) to the
module outlet (4) and place it in the water tank.
EN
E
Connect the water temperature sensor (16) to the
If you use any system to heat the water, maintain
the sensor away from it.
Connect the cables of the peripherals to the
sensor and actuator plugs (2/10). Each Plug is
divided in two secons, one for each device.
Perform the following steps to correctly connect
them without generang polarity problems.
8
