- 35 -
Maximum SIDE CHAIN output signal level, SIDE CHAIN XLR output:
+24 dBu, or 12.3 Vrms, 35 Vp-p. Subtract 6 dB (50%) for the
SIDE CHAIN TRS output jack.
Note that the SC output level is between 10 and 15 dB
lower then the program input signal, due to dynamic
range limitations of the op-amp based side-chain circuitry.
The side chain signals are not intended to be used as a source
of on-line production quality audio.
SIDE CHAIN EQualisation: Shelving, +/- 10 dB @ 50 Hz, and +/-
10 dB @10 kHz. Operates on INTernal SIDE CHAIN SOURCE mode
only.
GLORY EFFECT: 0 – 50% THD, mostly 2
nd
order, injection ratio
depending on instantaneous Gain Reduction, input signal and
output signal drive levels. Effect limited to 60 – 800 Hz
window; intended primarily for operation on fundamental signal
content of single or small groups of instruments or voices.
Operating temperature: 10 – 40 degrees C, 50 – 104 degrees F.
Operating humidity: 0 – 90 percent relative humidity, non-
condensing.
