Page #10 background imageLoading...
Page #10 background image
- 10 -
Technical specifications
Model
GZDSP 6-8X PRO
Type
8-channel signal processor (DSP)
Frequency Response
5 Hz 20 KHz
(-3 dB)
Signal to noise ratio
>115 dB
Channel separation
>70 dB
Harmonic distortion
0.05%
Processor
Cirrus Logic Single Core 32-bit, 8-channel, 192 kHz
Input sensitivity
High-level: 2 15 V RMS
Line (RCA): 0.6 5 V RMS
AUX input: 0.6 5 V RMS
Input impedance
>47 kΩ
Output
8 x RCA
Input
Main: 6x RCA (line) / 6 x high-level
AUX: 3.5 mm / 1/8“ stereo jack
Optical and coaxial digital input: max. 192 kHz stereo
Remote out
max. 500mA
Recomended fusing
2 A
Dimensions (heatsink)
W x H x L mm / inch
185 x 40 x 115 / 7.28“ x 1.57“ x 4.53
Software compatibility
Microsoft Windows™ XP SP3, Vista, 7, 8, 8.1,10
Presets
10 individual preset memory -
storing/calling a preset by using one of the optionally available remote control units
Gain bandwith
-40 ~ + 12dB
Equalizer
6x 31 bands on each channel (A-F) (20-20000Hz) -18 to +12dB, Q 0.5 - 9
2x11 bands on subwoofer channels (G/H) (20-200Hz), -18 to +12dB, Q 0.5 - 9
Time alignment
0 - 15ms / 0 - 510cm per channel
Crossover
6 / 12 / 18 / 24 / 30 / 36 / 42 / 48 dB/Oct. BPF / LPF / HPF Butterworth
20 - 20000Hz
Phase switch
0˚ / 180° per channel
Optional remote controls
GZDSP REMOTE PRO &
GZDSP TOUCH REMOTE
Main level and subwoofer level adjustable,
Input mode and preset selectable
