Product description
The GZDSP 6-8X PRO is a digital signal processor increasing the sound quality of the vehicle´s audio equipment.
Based on the 32-bit DSP processor in combination with a 24-bit AD and DA converter. Due to its audio summing
function combining 6 high-level channels and 31-band equalizing on each channel (11-bands on the subwoofer
channels), the GZDSP 6-8X PRO can be integrated into almost every OEM sound system even with OEM DSP.
Table of contents
Package contents
• 1 x GZDSP 6-8X PRO unit
• 1 x USB cable (A to B connector / 5.0 m)
• 1 x 6-channel high-level input harness
• 1 x Power supply harness
• 1 x CD-ROM incl. PC software and driver package
compatible to Microsoft Windows
®
XP SP3, Vista, 7, 8, 8.1 und 10
• 1 x Owner´s manual (German/English)
• 1 x Fastening kit
Optionally available:
• Remote control unit GZDSP REMOTE PRO
• Remote control unit GZDSP TOUCH REMOTE
• Streaming interface GZDSP BT-BOX
Package contents 2
General installation note 3
Connections 4
Power supply harness / High-level connector pinout / PC software installation 5
USB connection and COM port 6
Graphical user interface (GUI) 7
Time alignment setting (example) 8
Dropdown menu / Memory access restriction / Connection status 9
Technical specifications 10
Error diagnosis 11
Terms of warranty 12
