Growatt GBLI 6531 User Manual

Introduction to Product
9
2.4 Technical Parameters
No.
Item
Specification
1
Nominal capacity/energy
128Ah/6.5kWh
Rated/usable capacity/energy
118Ah/6.0kWh
2
Typical voltage
51.2 V
Operating voltage
48V ~57.6V
3
Standard charging current
(25℃)
64A
Max. discharging current
(25℃，3s)
96A
Continual Max. discharging
current (25℃)——85A
85A
4
Rated discharging power
3.3kW
Max. discharging power
4.4kW
Peak discharging power
5kW/3S
Rated charging power
3.3 kW
Max. charging power
3.5 kW
5
Max. Short circuit current peak
2000A
6
Operating temperature range
-10℃~45℃
Optimal operating temperature
0℃~30℃
7
Storage conditions
Within 6 month after initial charge
temperature: -20℃ ~ +45℃
humidity: 5% RH -95%RH
8
Room temperature cycle
life(25°C)
≥6000 cycles/60%EOL
9
Cooling
Natural cooling
10
Dimension
W475*D133*H745 mm
11
Weight
58kg±1Kg
12
Installation
Wall-mounted installation/floor
standing installation
13
Ingress protection
IP55
14
Cell safety certification
IEC62619/UL1973
15
Battery safety certification
IEC62619/CE/RCM/UL1973/CEC
16
Transportation test standard
UN38.3+PI965(sea)
17
Network port
CAN2.0B*1CH; RS485*1CH
18
Maximum parallel-connected
batteries
Two batteries
19
Protective class
I
20
over voltage category
II
21
External bipoles circuit
breaker required for battery
output
80V, 100A, 2P
