Growatt MOD 5000TL3-X User Manual

53
54
Model
Specifications
MOD
3000TL3-
X
MOD
4000TL3-
X
MOD
5000TL3-
X
MOD
6000TL3-
X
MOD
7000TL3-
X
MOD
8000TL3-
X
Protection devices
DC reverse-polarity
protection
YES
DC switch
YES
DC Surge protection
typeII OPT
Insulation resistance
monitoring
YES
AC surge protection
typeII OPT
AC short-circuit
protection
YES
Grid monitoring
YES
Anti-islanding protection
Integrated(ActiveFrequencyDrift)
Residual-current
monitoring unit
YES
String Fuse protection
NO
String monitoring
OPT
AFCI protection
OPT
General data
Dimensions (W / H / D) in
mm
425*387*147mm
425*387* 178mm
Weight
12.5kg
14kg
Operating temperature
range
-25°C ... +60°C
(>45°CDerating)
Noise emission (typical)
≤35dB(A)
Altitude
4000m
Internal consumption at
night
1W
Topology
Non-isolated
Cooling
Natural heat dissipation
Electronics protection
degree
IP66
Relative humidity
0~100%
DC connection
H4/MC4(OPT)
AC connection
Waterproof PG head+OT terminal or quick connect terminal
Interfaces
Display
OLED+LED
USB/RS485
YES
WIFI/GPRS/4G/RF/LAN
OPT
Model
Specifications
MOD
9000TL3-X
MOD
10KTL3-X
MOD
11KTL3-X
MOD
12KTL3-X
MOD
13KTL3-X
MOD
15KTL3-X
Input data(DC)
Max. recommended PV
power(for module STC)
13.5kW
15kW
16.5kW
18kW
19.5kW
22.5kW
Max. DC voltage
1100V
Start voltage
200V
Min. operating voltage
140V
Nominal voltage
580V
MPP voltage range
140-1000V
No. of MPP trackers
2
No. of PV strings per MPP
trackers
1/1
1/1
1/1
1/2
1/2
1/2
Max. input current per MPP
trackers
13/13A
13/13A
13/13A
13/26A
13/26A
13/26A
Max. short-circuit current
per MPP trackers
16/16A
16/16A
16/16A
16/32A
16/32A
16/32A
Backfeed current to PV array
0A
Output data(AC)
Rated output power
9000W
10kW
11kW
12kW
13kW
15kW
Max. AC apparent
9900VA
11kVA
12.1kVA
13.2kVA
14.3kVA
16.5kVA
Nominal AC voltage/range
230/400V
AC grid frequency/range
50/60 Hz
45~55Hz/55-65 Hz
Rated apparent power
3300VA
4400VA
5500VA
6600VA
7700VA
8800VA
Max. output current
15A
16.7A
18.3A
20.0A
21.7A
25A
Max output overload
protection
50A
63A
Max. inrush current(Peak
value/duration time)
10A/5ms
15A/5ms
AC inrush current
30A
Max. output fault
current(Peak value/duration
time)
44.5A/10us
58.4A/10us
Max. output fault current
44.5A
58.4A
Max. output overcurrent
Protection
44.5A
58.4A
Power factor(@nominal
power)
>0.99
Adjustable power factor
0.8Leading ...0.8Lagging
THDi
<3%
AC grid connection type
3W+PE /3W+N+PE
Overvoltage category
PV:II AC:III Others:I
Efficiency
Max. efficiency
98.6%
Euro-eta
97%
