Growatt MOD 5000TL3-X User Manual

59
60
Model
Specifications
MOD
9000TL3-
X-AU
MOD
10KTL3-
X-AU
MOD
11KTL3-
X-AU
MOD
12KTL3-X
MOD
13KTL3-X
MOD
15KTL3-X
Protection devices
DC reverse-polarity
protection
YES
DC switch
YES
DC Surge protection
typeII OPT
Insulation resistance
monitoring
YES
AC surge protection
typeII OPT
AC short-circuit
protection
YES
Grid monitoring
YES
Anti-islanding protection
Integrated(ActiveFrequencyDrift)
Residual-current
monitoring unit
YES
String Fuse protection
NO
String monitoring
OPT
AFCI protection
OPT
General data
Dimensions (W / H / D) in
mm
425*387* 178mm
Weight
16.0kg
Operating temperature
range
-25°C ... +60°C
(>45°CDerating)
Noise emission (typical)
≤35dB(A)
Altitude
4000m
Internal consumption at
night
1W
Topology
Non-isolated
Cooling
Natural heat dissipation
Electronics protection
degree
IP66
Relative humidity
0~100%
DC connection
H4/MC4(OPT)
AC connection
Waterproof PG head+OT terminal or quick connect terminal
Interfaces
Display
OLED+LED
USB/RS485
YES
WIFI/GPRS/4G/RF/LAN
OPT
17.3 Torque
Shell cover screw
22kgf.cm
AC terminal block
8kgf.cm
AC waterproof cover fixing screw
8kgf.cm
Security screws on the wall mount
12kgf.cm
Ground screw
12kgf.cm
17.4 Annex
Product attachments can be selected from the table below:
The monitoring equipment is not standard,it needs to be purchased
separately. As for detailed installation and use methods, please refer to
its own manual.
Information
17.2 DC connector and Isolator info(Australia model only)
DC connector
VP-D4/ MC4(opt)
Isolator*
NDG3V-50
Rated insulation voltage
1500V
Rated impulse withstand voltage
8kV
Suitability for isolation
Yes
Rating thermal current(Ith)
63A
Rated operational current(Ie)
55A
Utilization category and/or PV utilization
category
DC-21B/PV2
Rated short time withstand current (Icw)
700A
Rated short-circuit making capacity (Icm)
1.4kA
Rated breaking capacity
220A
*Only for Australia market.
