MOUNTING METHOD
FLOOR INSTALLATION
NOAH 2000 supports stacked installation, with a recommended maximum of 4 units.
Fix-bracket can be used to enhance stability as follows:
1. Install Fix-Bracket onto NOAH 2000 (Torque 1.5N·m).
2. Mark the wall after positioning NOAH 2000.
3. Drill holes(Ф6*30mm) at the marked spots , and insert expansion plugs.
4. Secure NOAH 2000 to the wall (Torque 1.2N·m).
5. The stacking should appear as shown in the illustration.
