Growatt ShineLink-X Quick Installation Manual

Aer the installaon, if the LED light of ShineRFSck-X ashes quickly, it means that the
installaon works. If the LED light is o, please recheck the connecon between ShineRFSck
and the inverter.
ShineRFSck -x’s LED status
Status of the ShineRFSck-X
Always on
The ShineRFSck-X is inialing
Always o
Lost connecon
Flashing quickly (every 0.2 second)
USB port found the inverter
Flashing slowly (every 1 second)
The connecon is working
ShineLanBox Electrical Connecon
Connect the ShineLanBox’s RJ45 port to the router, then connect the ShineLanBox with a
power adapter.
Aer inializaon of the ShineLanBox, the power LED is on, the network LED is on and the
device LED is ashing frequently.
If the power LED is on, it means that it is connected to the power supply.
If the network LED is on, it means that the ShineLanBox is connected to the internet.
If the device LED ashes, it means that the device works.
The number of ashing mes means the number of RF.
ShineLanBox LED lights
Status of working condion
Power light
If the light is on, it means that the power is on
Web light
Flashing means that it connected to router
Device light
The number of ashing means the number of devices connected to the
ShineLanBox
Paired light
Flashing when pairing, it turns o if the pairing has been successful
Item
Name
Descripon
A
Power input
Connected to the power
adapter
B
RS 485
Resaved
C
RJ 45
Connected to the network
D
Key
Funcon key
E
Conguraon LED
Conguraon of the device
F
Device LED
Device number is connected
G
Network LED
Connecng to the network
H
Power LED
Connecng to the power
