GrowSpan 2000 Series - Vent End Frame Diagram (B)

7
Revision date: 12.06.19 GK2EW24120B_G
Vent End Frame Diagram (B)
3'-5"
4'-2"
8'-10" 4'-2" 3'-5"
2'-3 3/8"
4'-3"
2'-10 5/8"
1'-1 3/8"
B B BB
GT
T
T
C1
TOP OF POST
GROUND LEVEL
GT
GT
T
GT
C2
C1
C2
GT
GT
GT
GT
GT
T
GT
QH1070
(PIPE STRAP)
LB
LATERAL BRACING BRACKET:
C2
PG2X2EC14L16200
(2" x 2" 14 GA 1-PLY SQUARE TUBE)
COLUMN BOTTOM BASE PLATE:
B 111817
(BASE PLATE)
COLUMN TOP CONNECTION PLATE:
PGBRKAAS01
(CONNECTION PLATE)
T
111635
(14 GA PROFILE)
GT
GIRT/DOOR FRAME
PG2X2EC14L13800
(2" x 2" 14 GA 1-PLY SQUARE TUBE)
C1
ENDWALL COLUMNS:
NOTES:
ALL DIMENSIONS ARE FROM CENTER TO CENTER UNLESS
OTHERWISE NOTED.
GIRTS/FRAMING CHANNEL MAY REQUIRE FIELD CUTTING TO FIT.
GRT2X2G16L144 (16 GA PROFILE)
IMPORTANT: IF A GUILLOTINE VENT WAS
PURCHASED TO INSTALL IN THE END
WALL, CONSULT THE INSTRUCTIONS
INCLUDED WITH THAT KIT FOR
REQUIRED VENT DIMENSIONS AS THEY
MAY DIFFER FROM THOSE SHOWN.
