KIT PART # KIT DESCRIPTION CONSTITUENT PART # CONSTITUENT DESCRIPTION
CONSTITUENT
REFERENCE
FROM OIPM
QTY.
PER KIT
FPM/KIT/SK Seal Kit
ORG/BS154 O Ring 7 1
ORG/V/BS809 O Ring (Viton) 16 1
ORG/BS126 O Ring 3 1
SEL/FPM/12 Seal (Metal Inserted) 15 1
FPM/KIT/GK Gear Kit
GEAR/FPM/12 Gear 8 2
KEY/GEAR/FPM/12 Key (Gear) 9 1
FPM/KIT/SA
Switch Assembly
Kit
CAM/SWH/FPM/12 Cam (Switch) 30 1
CVR/NZL/FPM/12 Cover (Nozzle) 37 1
LVR/FPM/12 Lever 35 1
BKT/SWH/FPM/12 Bracket (Switch) 28 1
SCR/CAM/FPM/12 Screw (CAM) 29 2
SFT/LVR/FPM/12 Shaft (Lever) 32 1
CVR/SWH/FPM/12 Switch Cover (M/C) 33 1
NN/M6/RP-G Nylock Nut 36 1
LOC/FPM/12 Lock 38 1
RVT/FPM/12 Rivet 39 1
TFS/M4/FPM/12 Thread Forming Bolt Screw M4 31 2
SWH/FPM On Off Toggle Switch 27 1
FPM/KIT/PC
Power Cable
Assembly Kit
SA/PCLE/FPM/12/HF Power Cable 43 1
